14.8 kW Dual Gun Charger
Category: AC Chargers
₹35,999
₹46,499 22% off
Inclusive of GST (5%)
Shipping charges extra
Sleek wall-mounted premium design
Tough and Long-Lasting
Emergency stop switch for safety
Excellent After-Sales Service
The EVFAST14.8 kW Dual Gun AC EV Charger is a high-performance charging solution designed to charge two electric vehicles simultaneously. Equipped with two independent Type-2 charging guns, each delivering 7.4 kW AC power, this charger is ideal for residential societies, commercial buildings, offices, fleet depots, and semi-public charging locations.
With a total combined output of 14.8 kW, the charger ensures efficient power utilization, faster charging, and reliable performance. Its compact and robust design makes it suitable for both indoor and outdoor installations, supporting the growing demand for multi-vehicle AC charging infrastructure.
Choose how you charge with three modes— Plug &Charge ,RFID and App based.
General
| Feature | Specification |
| Model | EVFAST 14.8Kw Dual Gun |
| Rated Capacity | 14.8 kW |
Input Parameters
| Feature | Specification |
| Input Supply | Three Phase AC |
| Input Voltage | 415 VAC (Operating Range: 380–440 VAC) |
| Input Frequency | 50 Hz ±1 Hz |
| Total Harmonic Distortion (THD) | ≤ 5% of nominal voltage |
| Power Factor | ≥ 0.99 at full load |
| Wiring Configuration | L1, L2, L3, Neutral (N), Protective Earth (PE) |
Output Parameters
| Feature | Specification |
| Output Voltage | 230 VAC ±15% per output |
| Number of Outputs / Connectors | 2 |
| Charging Power Distribution | 7.4 kW × 2 Output |
| Standard Connector Type | Type 2 Gun |
| Charging Standard | IEC 62196-2 |
| Overall Efficiency | > 95% |
Protection & Safety
| Feature | Specification |
| Protections | Over-Voltage, Under-Voltage, Over-Current, Short-Circuit, Ungrounded, A-Type Earth Leakage Protection |
USER INTERFACE & CONTROLS
| Feature | Specification |
| Display | 20 × 4 Jumbo LCD with LED indicators |
| Language Support | English |
| Emergency Control | Red Emergency Stop Button |
| Status Indication | Input supply, charging, and error status |
| Network Communication | 4G/Wi-Fi |
| OCPP Support | OCPP 1.6 or above |
| User Authentication | Plug & Play, RFID and App based |
Mechanical & Environmental
| Feature | Specification |
| Ingress Protection Rating | IP54 |
| Cooling Method | Natural Air Cooling |
| Charging Cable | Not included (Socket-Based Charger) |
| Operating Temperature Range | –20°C to +55°C |
| Storage Temperature Range | –20°C to +55°C |
| Humidity | 5% to 95% RH (Non-Condensing) |
| Installation Altitude | Up to 2000 m above sea level |
Simple Installation Requirements
Power:
Install a 63 A 4-Pole Miniature Circuit Breaker (MCB) to provide power to the charger.
Wiring:
Use 10 sq. mm pure copper cable to safely handle the electrical load.
Earthing:
Proper earthing is mandatory to avoid electric shocks & hazards.
Note:
In areas with frequent or extreme voltage fluctuations, install a voltage stabilizer before the MCB for added protection.
At EVFAST, we stand behind the quality and reliability of our EV Chargers, to give you complete peace of mind.
EVFAST products come with a 1-year warranty against manufacturing defects.
Accessories & Add-ons:
These items are not covered under warranty.
Warranty Exclusions:
The warranty does not apply to damage caused by power surges, supply-side electrical faults, burnouts, improper installation or usage, accidents, physical damage, unauthorized repairs or modifications.
